| Length | 467 mm |
| Width | 390 mm |
| Height | 250 mm |
| Weight in Air (With Ballast) | 9 - 10 kg |
| Pay load Capacity | 1 kg |
| Maximum Rated Depth | 100 m |
| Temperature Range | - 4 0 ° C to + 125 ° C |
| Maximum forward speed | 1.5 m / s |
| Endurance (Normal use) | ~ 2 hours w / 18 AH |
| Endurance (Light user) | ~ 4 hours w / 18 AH |
| Lights | 4 Lights 1500 lumens with brightness Control |
| Light beam angle | 135 degree, with adjastable tilt |
| Tilt Range | + / - 90 degree camera tilt (180 to talrange ) |
| Tilt Servo | HS - 5055MG |
| Field of view (underwater) | 110 degrees( horizontal) |
| Light sensitivity | 0.01 lux |
| Resolution | 1080 p |
| Tether Inter face Board | Connection to Surface Computer |
| Diameter | 7.6 mm |
| Length | 150 m |
| working strength | 45 kg f |
| Breaking strength | 160 kg f |
| Strength member | Kevlar with water block |
| Buoyancy fresh water | Neutral |
| Buoyancy salt water | slightly positive |
| Gyroscope | 3 - DOFG yro scope |
| Accelerometer | 3 - DOF Accelerometer |
| Compass | 3 - DOF Magnetometer |
| Internal pressure | Internal barometer |
| Pressure/depth and Temperature sensor (external) | External Barometer - Max 30 Bar |
| Current and voltage sensing | Power sense Module |
The JVM-100 is an observation class ROV that goes up to a depth of 100m and gives you live HD videos. Its HD Camera gives real-time view to the user at an instant. With high endurance provided by multiple batteries and a tether length of up to 150 m, it is the perfect ROV for moderately demanding underwater inspections and operations. The JVM-100 is also designed for carrying custom payloads as per the requirement of the operation having a range of attachments and sensors
